Standard Lift Control Panel

Interested in this product?

Simply fill out our online enquiry form and we will get back to you...

Key Features

TVC can offer a range of lift control panels within less than 2 weeks where urgent replacements are required.  The standard lift control panel is offered in geared, gearless and MRL options.

Geared, Gearless and MRL inclusions

  • Contract speed 1.6m/s maximum
  • E300 NIDEC drive 30A
  • Up to 8 floors, full collective including standard landing call module
  • Limax3CP (No physical limits or DZ required)
  • 1 car entrance. Doors fully automatic car and landing
  • Door operator – Electronic (i.e. GAL VVVF, FERMATOR VVVF, SEMATIC VVVF or SELCOM VVVF)

Gearless and MRL inclusions

  • Dual brake
  • Ethos handwind position display and panel mounted handwind switch
  • Handwind switch brake pushes

MRL inclusions

  • Midi MRL landing cabinet
  • Midi drive shaft mounted cabinet
  • MRL consumer unit
  • Cabinet light
  • MRL cabinet Interconnection cables
  • 3 phase isolator

Need more options?

  • TVC supplied Dewhurst CX-Basic/Speech Encoders
  • TVC 24-way output card standard – Optional output configuration for 3rd party indicators
  • TVC serial indicators & Node
  • EMU Gateway
  • EM181 with router
